PTFE Coated Glass Fabric and Industrial PTFE Solutions
KOLOFOL supplies PTFE coated glass and aramid fabrics, self-adhesive tapes, heat-sealing and zone tapes, as well as custom PTFE conveyor belts. The range covers a broad industrial product portfolio with custom cutting and converting.
Why PTFE coated glass fabric?
The PTFE coating and glass-fabric substrate combine properties that are particularly valuable in heat processing, packaging, food, electrical and general industrial processes.
Non-stick surface
Low friction and excellent release when processing sticky or molten materials.
-73 °C – +260 °C
Wide operating-temperature range for PTFE coated fabrics.
Chemical resistance
Excellent resistance to many industrial chemicals.
Electrical properties
High dielectric strength and low electrical losses in specialist grades.
Dimensional stability
The glass-fabric substrate provides a stable mechanical base under heat and pressure.
Specialist coatings
Food-grade, antistatic, abrasion-resistant, water/stain-repellent and aramid-substrate solutions.
Standard, premium and specialist PTFE coated fabrics
PTFE coated glass fabrics are available in multiple constructions for release surfaces, heat sealing, packaging, food processing, laminating, electrical insulation and conveyor applications. Selection depends on thickness, PTFE content, surface finish, mechanical load and required width.
- Electrical series
- Premium series
- Standard series
- Industrial series
- Mechanical series
- Tear- and crease-resistant series
- Antistatic black series
- Open-mesh and porous series
- PTFE coated aramid fabric
- Heavy belting series
- Master series
- Cook series
- Food series
- PVC-Weld series
- Other application-specific grades
Common PTFE coated glass fabric grades
| Product | Typical standard width | Nominal thickness | Weight | Typical application |
|---|---|---|---|---|
| NYS | 1000 / 1220 / 1520 mm | 0,073 mm | 135 g/m² | Economical industrial release surface |
| TIS | 1000 / 1200 / 1500 mm | 0,114 mm | 240 g/m² | General industrial use |
| THS | 1000 / 1220 / 1500 mm | 0,128 mm | 272 g/m² | Packaging, heat sealing, release |
| TOS | 1000 / 1500 mm | 0,142 mm | 296 g/m² | Premium, very smooth surface |
| HOS | 1000 / 1200 / 1500 mm | 0,235 mm | 490 g/m² | Premium heavy-duty industrial grade |
| HOS-E | 1000 / 1500 mm | 0,245 mm | 490 g/m² | Premium high-PTFE grade |
| HOS-3 | 1000–2750 mm | 0,250 mm | 534 g/m² | Wide grade, premium surface |
| HRS | 1000 / 1500 mm | 0,340 mm | 680 g/m² | Heavy premium grade |
Note: manufacturer specifications may change, and some grades may have minimum order quantities or different availability. We verify the current manufacturer specification when quoting.
Self-Adhesive PTFE Glass Fabrics and PTFE Tapes
A pressure-sensitive adhesive is applied to one side of the PTFE coated glass fabric. Products can be supplied in rolls, sheets or slit into narrow tapes.
Silicone adhesive
High-temperature adhesive system for applications up to 260 °C, typically with a yellow corrugated release liner.
Acrylic adhesive
Alternative adhesive system, typically for applications up to 180 °C, with a smooth blue release liner.
Slitting
The range supports wide master rolls and slitting into narrow tapes down to 5 mm.
Electro
High PTFE content, excellent release, chemical resistance and electrical strength. Typical grades: NYS-Ec, TOS-Ec.
Antistatic black
For applications requiring a conductive antistatic coating. Typical grades: ANS, AHS, AHOS, AHRS.
Special adhesive grades
Metal-detectable, acrylic-adhesive, self-wound linerless, PVC-Weld and other application-specific products.
Standard self-adhesive series – typical grades
| Product | Substrate weight | Nominal thickness | Adhesive | Standard width |
|---|---|---|---|---|
| NYT | 135 g/m² | 0,073 mm | 0,040 mm | 1000 / 1220 mm |
| TKT | 240 g/m² | 0,115 mm | 0,050 mm | 1000 / 1500 mm |
| THT | 272 g/m² | 0,128 mm | 0,050 mm | 1000 / 1500 mm |
| TOT | 296 g/m² | 0,142 mm | 0,050 mm | 1000 / 1500 mm |
| HOT | 490 g/m² | 0,235 mm | 0,065 mm | 1000 mm |
Heat-Sealing Tapes and Zone Tapes
In impulse and continuous film-sealing equipment, PTFE tape forms a non-stick, heat-resistant release surface between the heating element and the film.
- Fully self-adhesive PTFE glass-fabric tape
- Zone construction: the central heating zone can remain adhesive-free
- Reinforced edges and custom zone widths
- Custom overall width, length and roll size
- Silicone or acrylic adhesive depending on the application
- PVC-Weld for specialist PVC welding applications
The PVC-Weld family combines a smooth PTFE surface with a specialist adhesive system for PVC welding; the manufacturer lists brown, red and green versions.
Request a zone-tape quote
How to specify the tape dimensions
When ordering, please specify three dimensions: the total tape width the working area width and the thickness. The total tape width is the complete outside width of the tape, while the working area is the width of the central zone actually used in the sealing process.
PTFE Conveyor Belts and Endless Belts
Conveyor belts made from PTFE coated glass or aramid fabric for heat processing, drying, cooking, laminating and packaging processes.
- Closed-surface PTFE glass-fabric belts
- Open-mesh grades for processes requiring air and heat flow
- Aramid substrates for higher mechanical loads and smaller roller diameters
- Antistatic grades
- Custom width and endless length
- Different joint and edge-reinforcement solutions
- Welding tools for on-site joining and repairs
the manufacturer also offers welding presses, hand irons and heating bars for manufacturing and repairing PTFE belts; its range includes 1500 and 2000 mm workshop presses, a smaller 250 × 500 mm press, and 500 and 1000 mm heating bars.
Application-Specific PTFE Fabrics
Alongside standard products, KOLOFOL offers ranges optimized for specific industries. Selection is based on application, surface requirements, abrasion, heat load and mechanical stress.
PTFE coated aramid fabric
Combines PTFE release with the higher mechanical strength of an aramid substrate. Useful with small rollers, steam and demanding environments.
Master series
Food-processing belt material for fatty, aggressive cooking processes: strong release, resistance to oil penetration, good heat transfer and abrasion resistance.
Cook
High-PTFE, extra-smooth food belt material for meat, tortilla, biscuit and other demanding cooking applications.
Food
Special PTFE coated product family developed for food-processing applications.
Patch
Metal-detectable repair tape for food belts where removed tape fragments must be detectable.
Wind
Release solution developed for resin-infusion processes in composites and wind-blade manufacturing, with smoother, more abrasion-resistant grades.
Antistatic
Black conductive PTFE coatings for industrial processes requiring reduced static charge.
Open mesh / porous
For processes where air, gas or heat must pass through the conveyed product.
Abrasion-resistant grades
Coatings and substrates optimized for higher mechanical loads.
PTFE coated aramid – examples from the manufacturer's range
| Product | Standard width | Nominal thickness | Weight |
|---|---|---|---|
| 1270646KHT / KAS | 1250 mm | 0,160 mm | 200 g/m² |
| 1271546K | 1390 mm | 0,360 mm | 470 g/m² |
| 1271546KAS | 1390 / 2000 / 2300 mm | 0,370 mm | 570 g/m² |
| 1271746KAS | 1600 mm | 0,420 mm | 630 g/m² |
| 12730546K, open mesh | up to 3600 mm | depends on grade | depends on grade |
Where is it used?
Packaging
Film-sealing jaws, impulse sealers, bag making, heat sealing and sliding surfaces.
Food processing
Cooking belts, grill and oven liners, tortilla, biscuit and meat processing, and high-speed commercial toaster belts.
Textiles and laminating
Heat pressing, laminating, drying and release of adhesive or resinous materials.
Composite manufacturing
Hand lay-up, heated presses, RTM, autoclave/vacuum bagging, resin infusion and release surfaces.
Electrical industry
Applications requiring high dielectric strength, heat resistance and low electrical loss.
General industry
Chemical-resistant, non-stick, low-friction covers, guides, sliding surfaces and conveying.
Custom Cutting and Converting
We supply more than raw material: we can also prepare the finished or semi-finished PTFE product required for the application.
Rolls and sheets
PTFE coated fabrics as full rolls or cut-to-size sheets.
Narrow tapes
Self-adhesive and non-adhesive grades slit to custom widths.
Zone tape
Custom adhesive-free zones, widths and lengths for packaging machinery.
Conveyor belts
Custom width, endless length, joint and edge construction.
Material selection
Support selecting thickness, surface, adhesive, antistatic or aramid grade.
Samples and technical consultation
We can quote from an existing tape, drawing, part number or application parameters.
Frequently Asked Questions
What is PTFE coated glass fabric?
A glass-fabric substrate coated with PTFE. PTFE provides a non-stick, chemical-resistant surface while the glass fabric provides mechanical support and dimensional stability.
What temperature range can it handle?
KOLOFOL generally specifies a range of -73 °C to +260 °C for PTFE coated glass fabrics. For self-adhesive grades, the adhesive system's temperature resistance must also be considered.
When should a Premium grade be selected?
When an especially smooth surface, high PTFE content, improved release, chemical resistance or higher electrical insulation performance is required.
What is the difference between silicone and acrylic adhesive?
Silicone adhesive is suited to higher-temperature applications; Acrylic adhesive products are typically intended for applications up to around 180 °C.
Can custom widths be supplied?
Yes. Rolls, sheets, narrow tapes, zone tapes and conveyor belts can all be supplied in custom dimensions.
What information is needed for a quotation?
Preferably a part number or existing sample, total thickness, width, length, quantity, adhesive requirement, operating temperature and a brief description of the application.
Request a Quote for PTFE Fabric or Tape
Send the product code, required dimensions and quantity, or describe the application. We can help select the appropriate PTFE fabric, adhesive tape, zone tape or conveyor belt.
